Measuring range: 500 kg/m³ to 2,000 kg/m³
Accuracy in adjusted range: 1 kg/m³
Process temperature:
SST: 10°C to 80°C
GLS: -10°C to +60°C
CIP/SIP temperature and duration: SST: 95 °C for 30 min
Ambient temperature: -10 °C to +40 °C
Process pressure absolute:
SST: max. 16 bar
GLS: max. 6 bar
Material of the wetted parts:
SST: 1.4571, 1.4404, PVDF, Viton
GLS: glass, PVDF, Kalrez
Communication: Analog, RS-232, RS-485, Relay
Process connections: G 1/8"
U-tube inner diameter:
SST: 2.1 mm
GLS: 2.1 mm
Recommended flow rate:
SST: 10 L/h to 80 L/h
GLS: 10 L/h to 70 L/h
Dimensions: 166 mm x 155 mm x 91 mm
Standard adjustment range: 500 kg/m³ to 2,000 kg/m³
Weight: 1,800 g
