Dimensions: 202 x 60 x 30 mm (8 x 2.4 x 1.2 in)
Weight: 280 g
Viscosity Range: 30 – 3,500 cPs
Fluid Dispense Technology: Divorced Needle Valve with Atomization
Dispense Pattern: Cone Shaped
Dispense Width: 4 ~ 12 mm (0.15 ~ 0.5 in)
Operating Pressure: 0.4 – 0.7 Mpa
Fluid Pressure: 0 – 0.5 Mpa
Working Frequency: ≥ 400 per min
Medium: Clean Dry Compressed Air or Nitrogen (filtered & oil free)
Operating Temperature: Ambient
Control: High Speed Solenoid Valve
Fluid Inlet: Compression Fitting
