Core: ARM Cortex M4F
Data RAM Size: 128 kB
Data RAM Type: RAM
ADC Resolution: 16 bit, 24 bit
DAC Resolution: 12 bit
Data Bus Width: 32 bit
Interface Type: I2C, SPI, UART
Mounting Style: SMD/SMT
Number of I/Os: 36 I/O
Development Kit: MAX32680EVKIT
Watchdog Timers: Watchdog Timer
Moisture Sensitive: Yes
Program Memory Size: 512 kB
Program Memory Type: Flash
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 2 V
Analog Supply Voltage: 3.3 V
Number of ADC Channels: 12 Channel
Maximum Clock Frequency: 100 MHz
Number of Timers/Counters: 6 x 32 bit
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
