Shutdown: No Shutdown
Gain Error: 7 LSB
Input Type: Single-Ended
Resolution: 12 bit
Unit Weight: 593.500 mg
Architecture: SAR
Sampling Rate: 3 MS/s
Interface Type: SPI
Mounting Style: SMD/SMT
Reference Type: Internal
Development Kit: MAX19777EVSYS#
Power Consumption: 6.2 mW
Number of Channels: 2 Channel
Number of Converters: 1 Converter
Analog Supply Voltage: 2.2 V to 3.3 V
Digital Supply Voltage: 2.2 V to 3.3 V
Pd - Power Dissipation: 872 mW
FPBW - Full Power Bandwidth: 40 MHz
INL - Integral Nonlinearity: 3 LSB
SNR - Signal to Noise Ratio: 72.5 dB
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: 1.2 LSB
THD - Total Harmonic Distortion: - 83 dB
SFDR - Spurious Free Dynamic Range: 83 dB
SINAD - Signal to Noise and Distortion Ratio: 69 dB
