Gain: 2 dB
Technology: Si
IF Frequency: 0 Hz to 7 GHz
LO Frequency: 0 Hz to 9 GHz
RF Frequency: 0 Hz to 7 GHz
Mounting Style: SMD/SMT
NF - Noise Figure: 15.9 dB
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 2.7 V
Operating Supply Current: 40 mA
Operating Supply Voltage: 2.7 V to 3.6 V
P1dB - Compression Point: 6 dBm
OIP3 - Third Order Intercept: 21 dBm
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
