Height: 1.1 mm
Shutdown: No Shutdown
Gain Error: 41 LSB
Input Type: Differential/Single-Ended
Resolution: 12 bit
Unit Weight: 191 mg
Architecture: Pipeline
Sampling Rate: 80 MS/s
Mounting Style: SMD/SMT
Reference Type: Internal
Development Kit: DC699A-A
Number of Channels: 1 Channel
Analog Supply Voltage: 5 V
Pd - Power Dissipation: 1.45 W
INL - Integral Nonlinearity: 0.4 LSB
DNL - Differential Nonlinearity: 0.2 LSB
THD - Total Harmonic Distortion: - 87 dB
SFDR - Spurious Free Dynamic Range: 87 dB
SINAD - Signal to Noise and Distortion Ratio: 71.7 dB
