Gain: 13.5 dB
Technology: GaAs
Unit Weight: 18.490 g
Mounting Style: SMD/SMT
Test Frequency: 20 GHz to 30 GHz
Input Return Loss: 15 dB
NF - Noise Figure: 2.5 dB
Number of Channels: 1 Channel
Operating Frequency: 2 GHz to 30 GHz
Pd - Power Dissipation: 1.55 W
Operating Supply Current: 67 mA
Operating Supply Voltage: 5 V
P1dB - Compression Point: 13.5 dBm
OIP3 - Third Order Intercept: 24 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
