Gain: 20 dB
Technology: GaAs
Mounting Style: SMD/SMT
Test Frequency: 29 GHz to 33 GHz
Input Return Loss: 15 dB
NF - Noise Figure: 2.8 dB
Number of Channels: 1 Channel
Operating Frequency: 29 GHz to 36 GHz
Pd - Power Dissipation: 820 mW
Operating Supply Current: 80 mA
Operating Supply Voltage: 3 V
P1dB - Compression Point: 12 dBm
OIP3 - Third Order Intercept: 23.5 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
