Gain: 14 dB
Technology: GaAs
Unit Weight: 12.327 g
Mounting Style: SMD/SMT
Test Frequency: 6 GHz to 18 GHz
Input Return Loss: 22 dB
NF - Noise Figure: 2.5 dB
Number of Channels: 1 Channel
Operating Frequency: 0 Hz to 20 GHz
Pd - Power Dissipation: 2.17 W
Operating Supply Current: 60 mA
Operating Supply Voltage: 8 V
P1dB - Compression Point: 16 dBm
OIP3 - Third Order Intercept: 28 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
