Gain: 14 dB
Technology: GaAs
Mounting Style: SMD/SMT
Input Return Loss: 10 dB
NF - Noise Figure: 6.5 dB
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Operating Frequency: 17.5 GHz to 24 GHz
Pd - Power Dissipation: 491 mW
Operating Supply Current: 85 mA
Operating Supply Voltage: 5 V
P1dB - Compression Point: 21.5 dBm
OIP3 - Third Order Intercept: 27 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
