Gain: 18.5 dB
Technology: GaAs
Mounting Style: SMD/SMT
Test Frequency: 45 GHz to 75 GHz
Input Return Loss: 18 dB, 20 dB, 25 dB
Number of Channels: 1 Channel
Operating Frequency: 40 GHz to 80 GHz
Supply Voltage - Max: 4 V
Supply Voltage - Min: 3 V
Pd - Power Dissipation: 3.04 W
Operating Supply Current: 550 mA
Operating Supply Voltage: 3 V to 4 V
P1dB - Compression Point: 22 dBm
OIP3 - Third Order Intercept: 31 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
