Technology: GaAs
IF Frequency: DC to 10 GHz
LO Frequency: 5 GHz to 15 GHz
RF Frequency: 5 GHz to 30 GHz
Mounting Style: SMD/SMT
Development Kit: EVAL-ADMV1530
Conversion Loss - Max: 10 dB
Pd - Power Dissipation: 269 mW
P1dB - Compression Point: 13 dBm, 17 dBm
OIP3 - Third Order Intercept: 25 dBm, 27 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
