Gain: - 7.25 dB
Technology: SiGe
Unit Weight: 42.100 mg
IF Frequency: 10 MHz to 600 MHz
LO Frequency: 10 MHz to 6 GHz
RF Frequency: 10 MHz to 6 GHz
Mounting Style: SMD/SMT
Development Kit: ADL5801-EVALZ
NF - Noise Figure: 13.6 dB
Moisture Sensitive: Yes
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 4.75 V
Conversion Loss - Max: 1.8 dB
Operating Supply Current: 130 mA
Operating Supply Voltage: 5 V
P1dB - Compression Point: 9.9 dBm
Maximum Operating Frequency: 6 GHz
OIP3 - Third Order Intercept: 24 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
