Shutdown: Shutdown
Unit Weight: 104 mg
Settling Time: 13 us
3 dB Bandwidth: 10 MHz
Amplifier Type: Precision
Mounting Style: SMD/SMT
SR - Slew Rate: 74 V/us
Development Kit: EVAL-ADHV4702-1CPZ
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Supply Voltage - Max: 220 V
Supply Voltage - Min: 24 V
Ib - Input Bias Current: 2 pA
Operating Supply Current: 3 mA
Ios - Input Offset Current: 2 pA
Output Current per Channel: 20 mA
Vos - Input Offset Voltage: 150 uV
GBP - Gain Bandwidth Product: 10 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 1 fA/sqrt Hz
en - Input Voltage Noise Density: 8 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 140 dB
PSRR - Power Supply Rejection Ratio: 155 dB
