Gain Error: 1 %/FSR
Input Type: Differential
Resolution: 14 bit
Architecture: Pipeline
Sampling Rate: 1.3 GS/s
Interface Type: SPI
Mounting Style: SMD/SMT
Reference Type: Internal
Development Kit: AD9695-1300EBZ
Reference Voltage: 500 mV
Number of Channels: 1 Channel
Number of Converters: 1 Converter
Analog Supply Voltage: 950 mV, 1.8 V, 2.5 V
Digital Supply Voltage: 950 mV, 1.8 V
Pd - Power Dissipation: 1.39 W
FPBW - Full Power Bandwidth: 2 GHz
INL - Integral Nonlinearity: 1 LSB
SNR - Signal to Noise Ratio: 63.9 dB
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: 0.8 LSB
ENOB - Effective Number of Bits: 10.5 bit
SFDR - Spurious Free Dynamic Range: 68 dB
SINAD - Signal to Noise and Distortion Ratio: 61.8 dB
