Width: 0.36 mm
Height: 1.46 mm
Length: 2.96 mm
Shutdown: No Shutdown
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Unit Weight: 3 mg
Amplifier Type: Micropower Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 13 mV/us
Voltage Gain dB: 120 dB
Number of Channels: 4 Channel
Supply Voltage - Max: 5.5 V, +/- 2.5 V
Supply Voltage - Min: 1.8 V, +/- 900 mV
Ib - Input Bias Current: 10 pA
Operating Supply Current: 60 uA
Operating Supply Voltage: 1.8 V to 5 V
Vos - Input Offset Voltage: 500 uV
Maximum Dual Supply Voltage: +/- 2.5 V
Minimum Dual Supply Voltage: +/- 900 mV
GBP - Gain Bandwidth Product: 95 kHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 45 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 105 dB
PSRR - Power Supply Rejection Ratio: 110 dB
