Width: 16.66 mm
Height: 3.68 mm
Length: 16.66 mm
Gain Error: +/- 3 LSB
Input Type: Single-Ended
Resolution: 12 bit
Output Type: CMOS/TTL
Unit Weight: 2.387 g
Architecture: SAR
Input Voltage: +/- 5 V/+/- 10 V
Sampling Rate: 454 kS/s
Interface Type: Parallel, Serial
Mounting Style: SMD/SMT
Reference Type: External, Internal
Moisture Sensitive: Yes
Number of Channels: 8 Channel
Number of ADC Inputs: 8 Input
Number of Converters: 1 Converter
Supply Voltage - Max: 5 V
Supply Voltage - Min: 5 V
Analog Supply Voltage: 5 V
Digital Supply Voltage: 5 V
Pd - Power Dissipation: 100 mW
INL - Integral Nonlinearity: +/- 1 LSB
SNR - Signal to Noise Ratio: 70 dB
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: +/- 1 LSB
