Shutdown: No Shutdown
Gain Error: 10 FSR
Input Type: Differential/Pseudo-Differential
Resolution: 12 bit
Architecture: Sigma-Delta
Sampling Rate: 500 kS/s
Interface Type: SPI
Mounting Style: SMD/SMT
Reference Type: External, Internal, Supply
Development Kit: EVAL-AD4170-4ARDZ
Reference Voltage: 2.5 V
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Number of Converters: 1 Converter
Supply Voltage - Max: 6.35 V
Supply Voltage - Min: 1.7 V
Analog Supply Voltage: 4.75 V to 5.25 V
Digital Supply Voltage: 1.7 V to 5.25 V
Pd - Power Dissipation: 115 mW
FPBW - Full Power Bandwidth: 50 kHz
INL - Integral Nonlinearity: 2 LSB
SNR - Signal to Noise Ratio: 110 dBFS
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: 0.2 LSB
THD - Total Harmonic Distortion: - 120 dBFS
SFDR - Spurious Free Dynamic Range: 125 dBc
SINAD - Signal to Noise and Distortion Ratio: 109.5 dBFS
