Gain: 20 dB
Technology: GaAs InGaP
Unit Weight: 20.400 mg
Mounting Style: SMD/SMT
Input Return Loss: 8 dB
NF - Noise Figure: 7 dB
Number of Channels: 1 Channel
Operating Frequency: 2.2 GHz to 2.8 GHz
Supply Voltage - Max: 5 V
Supply Voltage - Min: 2.75 V
Pd - Power Dissipation: 1.755 W
Operating Supply Current: 300 mA
Operating Supply Voltage: 2.75 V to 5 V
P1dB - Compression Point: 27 dBm
OIP3 - Third Order Intercept: 39 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
