AC Voltage: 6.000 V, 60.00 V, 600.0 V, 1000 V ; +/- (1.0 % rdg + 3 LSD); @ 45 Hz to 400 Hz, 0 V to 600 V
DC Voltage: 600.0 mV, 6.000 V, 60.00 V; 600.0 V, 1000 V; +/- (0.5% rdg + 2 LSD); @ 6 V to 600 V ranges
AC Current: 600.0 μA, 6000 μA; 60.00 mA, 500.0 mA; 10.00 A ; ±(1.2% Rdg + 5 LSD); @ 600 μA to 6000 μA ranges,; 45 Hz to 400 Hz
DC Current: 600.0 μA, 6000 μA; 60.00 mA, 500.0 mA; 10.00 A ; ±(1.0% Rdg + 2 LSD); @ 600 μA to 6000 μA ranges
Frequency: 60.00 Hz, 600.0 Hz; 6.000 kHz, 60.00 kHz, 600.0 kHz,6.000 MHz, 60.00 MHz ; +/- (0.1% rdg + 3 LSD)
Resistance: 600.0 Ω; 6.000 kΩ, 60.00 kΩ, 600.0 kΩ; 6.000 MΩ 60.00 MΩ ; +/- (1.0% rdg + 2 LSD); @ 6 kΩ to 600 kΩ ranges
Capacitance: 60.00 nF, 600.0 nF; 6.000 μF, 60.00 μF, 600.0 μF, 6000 μF,60.00 mF ; +/- (3.0% rdg + 5 LSD); @ 600 nF to 60 μF ranges
Temperature: -40 ⁰F to 1832 ⁰F; -40 ⁰C to 1000 ⁰C
+/- (1.0% rdg + 12) @ >104 ⁰F to 752 ⁰F
+/- (1.0% rdg + 8) @ >40 ⁰C to 400 ⁰C
Number of temperature inputs: Dual Thermocouple
Duty cycle: 10.00% to 90.00% +/- (1.2% rdg + 30 LSD) @ 5 Hz to 2 kHz
Included Accessories:
9V(6F22) x1 battery installed
Test leads
Type-K probe x 2
Temperature adaptor
Velcro strap
Carrying case
Users manual
