AC Voltage: 400 mV, 4.000 V, 40.00 V,400.0 V, 600 V; +/- (1.0 % rdg + 3 LSD); @ 45 Hz to 400 Hz, 4 V to 400 V ranges
DC Voltage: 400 mV, 4.000 V, 40.00 V,400.0 V, 600 V; +/- (0.8% rdg + 1 LSD); @ 4 V to 400 V ranges
AC Current: 400.0 μA, 4000 μA,40.00 mA, 400.0 mA, 4.000 A, 10.00 A; +/- (1.2% rdg + 3 LSD); @ 400 μA V to 400 mA ranges
DC Current: 400.0 μA, 4000 μA,40.00 mA, 400.0 mA, 4.000 A, 10.00 A; +/- (1.2% rdg + 3 LSD); @ 400 μA to 400 mA ranges, 45 Hz to 400 Hz
Frequency: 10 Hz to 10 MHz +/- (0.1% rdg + 4 LSD); @ 400 μA to 400 mA ranges
Resistance:: 400.0 Ω, 4.000 kΩ, 40.00 kΩ, 400.0 kΩ, 4.000 MΩ, 40.00 MΩ; +/- (1.0% rdg + 2 LSD); @ 4 kΩ to 400 kΩ ranges
Capacitance: 40.00 nF, 400.0 nF,4.000 μF, 40.00 μF, 400.0 μF, 4000 μF ; +/- (3.0% rdg + 5 LSD); @ 400 nF to 40 μF ranges
Temperature: -40 °F to 1832 °F; -40 °C to 1000 °C
+/- (1.8% rdg + 6 °F) @ >32 °F to 212 °F
+/- (1.2% rdg + 3 °C) @ >0 °C to 100 °C
Number of temperature inputs Single Thermocouple
Included Accessories
Manufacturer: Amprobe
Model: AM- 520
Origin: TW
Warranty: 12 months
AC Voltage: 400 mV, 4.000 V, 40.00 V,400.0 V, 600 V; +/- (1.0 % rdg + 3 LSD); @ 45 Hz to 400 Hz, 4 V to 400 V ranges
DC Voltage: 400 mV, 4.000 V, 40.00 V,400.0 V, 600 V; +/- (0.8% rdg + 1 LSD); @ 4 V to 400 V ranges
AC Current: 400.0 μA, 4000 μA,40.00 mA, 400.0 mA,
4.000 A, 10.00 A; +/- (1.2% rdg + 3 LSD); @ 400 μA V to 400 mA ranges
DC Current: 400.0 μA, 4000 μA,40.00 mA, 400.0 mA, 4.000 A, 10.00 A; +/- (1.2% rdg + 3 LSD); @ 400 μA to 400 mA ranges,
45 Hz to 400 Hz
Frequency: 10 Hz to 10 MHz +/- (0.1% rdg + 4 LSD)
@ 400 μA to 400 mA ranges
Resistance:: 400.0 Ω,
4.000 kΩ, 40.00 kΩ, 400.0 kΩ, 4.000 MΩ, 40.00 MΩ; +/- (1.0% rdg + 2 LSD); @ 4 kΩ to 400 kΩ ranges
Capacitance: 40.00 nF, 400.0 nF,
4.000 μF, 40.00 μF, 400.0 μF, 4000 μF +/- (3.0% rdg + 5 LSD)
@ 400 nF to 40 μF ranges
Temperature: -40 °F to 1832 °F; -40 °C to 1000 °C
+/- (1.8% rdg + 6 °F) @ >32 °F to 212 °F
+/- (1.2% rdg + 3 °C) @ >0 °C to 100 °C
Number of temperature inputs Single Thermocouple
