Color: Gray
Gender: Plug (RP - Female)
Insulation: Insulated
Unit Weight: 10.535 g
Contact Type: Socket
Mating Gender: Receptacle
Contact Gender: Without Socket Contacts
Current Rating: 25 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Wire Gauge Max: 10 AWG
Wire Gauge Min: 14 AWG
Contact Material: Thermoplastic
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 10 AWG to 14 AWG
Mating Part Number: ATP04-4P
Number of Positions: 4 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
