Color: Black
Width: 25.6 mm
Height: 22.9 mm
Length: 47.7 mm
Dimensions: 47.7 mm x 25.6 mm x 22.9 mm
Insulation: Insulated
Contact Gender: Female
Current Rating: 25 A
Housing Gender: Male
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Wire Gauge Max: 10 AWG
Wire Gauge Min: 14 AWG
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 14 AWG to 10 AWG
Termination Style: Crimp
Number of Positions: 4 Position
Insulation Resistance: 1 GOhms
Operating Temperature Range: - 55 C to + 125 C
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
