Color: Gray
Width: 22.1 mm
Height: 14.7 mm
Length: 47.4 mm
Dimensions: 47.4 mm x 22.1 mm x 14.7 mm
Insulation: Insulated
Contact Gender: Female
Current Rating: 25 A
Housing Gender: Male
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 1 Row
Wire Gauge Max: 12 AWG
Wire Gauge Min: 14 AWG
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 14 AWG to 12 AWG
Termination Style: Crimp
Number of Positions: 2 Position
Insulation Resistance: 1 GOhms
Operating Temperature Range: - 55 C to + 125 C
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
