Color: Gray
Insulation: Insulated
Unit Weight: 5.844 g
Contact Type: Socket
Mating Gender: Receptacle
Contact Gender: Socket (Female)
Current Rating: 7.5 A
Housing Gender: Plug (Male)
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 1 Row
Wire Gauge Max: 16 AWG
Wire Gauge Min: 22 AWG
Contact Plating: Gold
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 22 AWG to 16 AWG
Termination Style: Crimp
Ingress Protection: IP67
Mating Part Number: ATM04-2P
Flammability Rating: UL 94 V-0
Number of Positions: 2 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
