Color: Black
Insulation: Insulated
Contact Type: Pin
Mating Gender: Plug
Contact Gender: Pin (Male)
Current Rating: 7.5 A
Housing Gender: Receptacle (Female)
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 1 Row
Wire Gauge Max: 16 AWG
Wire Gauge Min: 22 AWG
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 22 AWG to 16 AWG
Termination Style: Crimp
Ingress Protection: IP67
Mating Part Number: ATM06-2S
Flammability Rating: UL 94 V-0
Number of Positions: 2 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
