Color: Black
Pitch: 4.3 mm (0.169 in)
Gender: Receptacle (RP - Male)
Insulation: Insulated
Contact Type: Pin
Mating Gender: Plug
Current Rating: 13 A
Mounting Angle: Right Angle
Mounting Style: Through Hole
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Contact Plating: Tin
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 14 AWG to 20 AWG
Termination Style: Solder Pin
Ingress Protection: IP67
Mating Part Number: AT06-3S
Flammability Rating: UL 94 V-0
Number of Positions: 3 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
