Color: Black
Gender: Receptacle (Female)
Insulation: Insulated
Contact Type: Pin
Contact Gender: Pin (Male)
Current Rating: 13 A
Mounting Style: Panel Mount
Voltage Rating: 250 V
Wire Gauge Max: 12 AWG
Wire Gauge Min: 22 AWG
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 14 AWG to 12 AWG, 22 AWG to 14 AWG
Termination Style: Crimp
Ingress Protection: IP68, IP69K
Number of Positions: 15 Position
Insulation Resistance: 1 GOhms
Operating Temperature Range: - 55 C to + 125 C
Maximum Operating Temperature: - 55 C
Minimum Operating Temperature: + 125 C
Cable Diameter / Insulation Range: 3.05 mm to 4.01 mm
