Color: Red
Width: 18.3 mm
Gender: Plug (RP - Female)
Height: 23.1 mm
Length: 31.2 mm
Dimensions: 31 mm x 18.3 mm x 23.1 mm
Insulation: Insulated
Contact Type: Socket (Female)
Mating Gender: Receptacle
Contact Gender: Without Socket Contacts
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 3 Row
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 14 AWG to 20 AWG
Mating Part Number: AT04-6P
Number of Positions: 6 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
