Color: Gray
Width: 22.5 mm
Gender: Receptacle (Female)
Height: 21.2 mm
Length: 36.4 mm
Dimensions: 36.4 mm x 22.5 mm x 21.2 mm
Insulation: Insulated
Unit Weight: 15.892 g
Contact Type: Pin (Male)
Mating Gender: Plug
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: SMD/SMT
Number of Rows: 2 Row
Voltage Rating: 250 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Contact Plating: Nickel
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 14 AWG to 20 AWG
Termination Style: Solder Pin
Ingress Protection: IP67
Mating Part Number: AT06-08SXx
Number of Positions: 8 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
