Color: Black
Gender: Receptacle (RP - Male)
Length: 41.6 mm
Insulation: Insulated
Contact Gender: Pin (Male)
Current Rating: 7.5 A, 13 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Wire Gauge Max: 10 AWG
Wire Gauge Min: 14 AWG
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 10 AWG to 14 AWG
Termination Style: Crimp
Mating Part Number: AHDP06-18-20S
Flammability Rating: UL 94 V-0
Number of Positions: 20 Position
Description/Function: Size 18
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
