Color: Green
Gender: Plug (Male)
Insulation: Insulated
Unit Weight: 73.537 g
Contact Gender: Socket (Female)
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 14 AWG to 20 AWG
Termination Style: Crimp
Mating Part Number: AHD10-9-1939P, AHD17-9-1939P
Flammability Rating: UL 94 V-0
Number of Positions: 9 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
