Pitch: 1.27 mm
Card Type: PCMCIA
Orientation: Right Angle
Row Spacing: 1.27 mm
Mating Cycles: 10 k
Mounting Type: Top
Current Rating: 500 mA
Mounting Style: PCB Mount
Number of Rows: 2 Row
Voltage Rating: 5 V
Contact Plating: Palladium Nickel
Contact Material: Copper Alloy
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: Through Hole
Number of Contacts: 68 Contact
Flammability Rating: UL 94 V-0
Insulation Resistance: 1 GOhms
Insertion - Extraction Style: Manual-Manual (Slide In-Slide Out)
