Pitch: 3.96 mm (0.156 in)
Application: Wire-to-Board
Unit Weight: 1.280 g
Housing Color: Natural
Latching Type: Friction Lock
Contact Gender: Pin (Male)
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 1 Row
Contact Plating: Tin
Contact Material: Brass
Housing Material: Polyester
Termination Style: Solder Pin
Mating Post Length: 7.7 mm (0.303 in)
Flammability Rating: UL 94 V-0
Number of Positions: 5 Position
Termination Post Length: 3.7 mm (0.146 in)
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 25 C
