Amittari MT-200D2 Digital gaussian meter (0~200mT~2000mT)

Measuring range: 0~200mT~2000mT

Frequency range: 10Hz~200Hz

The accuracy of: DC,5%/AC,5%,10-200HZ (measured in a uniform magnetic field)

Resolution:

DC*1: 0.00~200.00mT 0.01mT

DC*10: 0.0~2000.0mT 0.1mT

AC*1: 0.00~200.00mT 0.01mT

AC*10: 0.0~2000.0mT 0.1mT

Magnetic field under test: DC magnetic field (static magnetic field); AC magnetic field (dynamic magnetic field)

Functional specifications: Peak retention Gs(Gauss) /mT (Millitesla) can be switched freely

Dc polarity of measurement: N for positive, S for negative

Operating Conditions: 5°C~40°C

Relative humidity: 20%~80% (There is no dew)

Power supply: 4x1.5V AAA (UM-4) Battery

Overall dimensions: The host: 140mm (L) X73mm (W) X 30mm (H)

Instrument weight: 180g

Display mode: 4½ LCD

According to the unit: mT/Gs

Standard Accessories: Main engine (one); Hall sensor (one); Operating Instructions (one copy)
