Capacity F(nom) (N ): 500N
Resolution( N): 0.5
Temperature coefficient (%/K): 0.02
Reproducibility (% F ): 0.06
Repeatability (% F ): 0.06
Hysteresis (% F ): 0.15
Creeping (5min) (% F ): 0.15
Measuring principle : Bidirectional force sensor with strain gauges and high-speed ?-processor
Nominal deflection( mm): 0.17
Measuring shaft : M6
Max. operating force % F(nom) : 120
Breaking force % F(nom): 500
Display:
Type : 5-digit LCD | 12mm | Autoreverse
Refresh time (ms): 1000
Operation modes:
Regular : N | kg | lb
Peak (real-time): -
Limits + Statistics : -
Interface:
USB: without
Hirose : without
Sensor: without
Power supply (Type ): internal LiPo battery | operation time 150h
Temperature (operation)( °C): 0 ... 40
Protection code (EN 60529) (Cable not plugged): Housing
Housing:
Material : A-Druckguss
LxWxH (mm) : 150 x 82 x 29
Weight (kg): 0.48
Mounting : 2xM4. 2xM5. adjusting holes D5(H7)
