Function
Channels: > 16
Suitable Detector: Detector with 4–20 mA only
Electric
Power Supply: 220 VAC
Power Consumption: Each channel ≤ 1 W
Signal Input: 4–20 mA
Signal Output: 4–20 mA
Wiring: Three-wire
Suitable Cable: RVVP 3×1.5 mm²
Relay Output: 2 passive relays (250 VAC / 5 A 30 VDC / 5 A)
Display & Operation
Display: OLED screen, resolution 128×64
Indicator Light: Power, fault, alarm-1, alarm-2
Operation Method: Button
Environment
Operating Temperature: 0 °C ~ 40 °C
Operating Humidity: 10 ~ 95 % RH (non-condensing)
Operating Pressure: 80–120 kPa
Structure
Body Material: Carbon steel with electrostatic spraying
Dimensions: 2100×800×600 mm (H×W×D)
