Configuration: NO, NO2, CO, O3, SO2, VOC, CO2, H2S, PM (PM10, PM2.5, PM1), Temperature, humidity, wind speed and wind direction, ambient noise, rainfall
Particulate Matter <10 µm (PM10) 0–6,000 µg/m3
Particulate Matter <2.5 µm (PM2.5) 0–6,000 µg/m3
Particulate Matter <1 µm (PM1) 0–6,000 µg/m3
Nitric Oxide (NO): 0–6,000 ppb Solar & UV Radiation
Nitrogen Dioxide (NO2): 0–10,000 ppb
Carbon Monoxide (CO): 0–8,000 ppb
Ozone (O3): 0–10,000 ppb
Sulfur Dioxide (SO2): 0–10,000 ppb
Carbon Dioxide (CO2): 0–10,000 ppm
Hydrogen sulfide (H2S): 0–2,000 ppb
Volatile Organic Compounds (VOCs): 0–40 ppm
Physical
Dimensions: 322mm × 239mm × 177 mm (12.7" × 9.4" × 7.0")
Weight: 2.2 kg (4.8 lbs)
Operating Temperature Range: -35 – +55°C
Operating Pressure Range: 30 – 110 kPa (4.35 – 15.95 psi)
Humidity Range: 0 – 95% RH
Communication: Ethernet, Wi-Fi, Worldwide Cellular Coverage (2G – 5G), LoRaWAN, Modbus over RS485 or TCP/IP
Enclosure Details
Material: Polycarbonate
Rating: NEMA 4 / 4X IP65 sealing
Mounting Options: Pole mount or wall mount (kits available)
Electrical
Power Supply: 9 – 36 VDC; PoE support
Power Consumption: Typical 5 W, Max 8 W
For more details, please see brochure.
