Working range
Voltage: 0-150V
Current: 0–2400A
Power: 60kW
Minimum working voltage: 1.8V@2400A
Constant current loading
Range: 240/1200/2400A
Resolution: 2/10/20mA
Accuracy: ±0.05%+0.05%F.S.
Constant voltage loading
Range: 16/80/150V
Resolution: 0.1/0.5/1mV
Accuracy: ±0.025%+0.025%F.S.
Constant resistance load
Range: 1.3mΩ–12.5Ω(16V), 5mΩ–50Ω(80V), 0.125Ω–250Ω(150V)
Resolution: 20mA/Vsense
Accuracy: ±Vin/Rset*0.2%+0.2%F.S.
Constant power loading
Range: 6000/30000/60000W
Resolution: 400/2000/4000mW
Accuracy: ±0.2%+0.2%F.S.
Current change rate
Setting range: 2mA/μs–24A/μs (240A), 10mA/μs–48A/μs (1200A), 20mA/μs–96A/μs (2400A)
Resolution: 2/10/20 mA/μs
Specification
Dimensions (W×H×D): 610 mm × 1720 mm × 800 mm
Weight: 469 kg
