Max. force: 500N (50kgf) / 2KN (200kgf)
Force accuracy: Depends on the load cell used.
Force measuring amplifier: Built in
Controller: Built in
Test speed: 5～300mm/min / 5～125mm/min
Speed changing: Numeric input (Settable on the PC)
Stroke: 390mm
Distance between test center and column: 100mm
Table size: W174×D200mm
Drive motor: Stepping motor
Detector: Rotary encoder
Display accuracy: ±0.2mm
Dimensions: W300×D400×H823mm
Stand mass: Approx. 40 kg
Power supply: Single phase, 100VAC – 240VAC 3A
Standard set: Tester, load cell(3000 Series or UP Series) 1 piece, software FTN-3001
Options: Additional load cell, jig/fixture
