No. Of Channel: 1
Form of Output: Single-ended output
Bandwidth（-3dB）: DC~1MHz
Max. Output Voltage: 200Vp-p
Range of Output Voltage:Range1：+40V~-160V
Range2：+100V~-100V
Range3：+160V~-40V
Max. Output Power: 50Wp
Fuse: 2A/250V
Voltage Gain: x0~60（0.1 step/1 step）
Upper Limit of Load RL: ≥395Ω（DC~50Hz）
≥195Ω（＞50Hz）
DC Offset: ±160V（0.1V step/1V step）
Voltage Range of DC Offset: Range1：+40V~-160V
Range2：+100V~-100V
Range3：+160V~-40V
Output Resistance: 5Ω /50Ω (customizable）
Input Resistance: 50Ω / 10kΩ
Input Amplitude: 0~10Vp-pMAX
Output Voltage Error: ≤±3%FS@1kHz
Voltage Monitor: 20mV/V
Current Monitor: 2V/A
Slew Rate: ≥445V/μs
THD: ≤0.1%@1kHz，100Vp-p
Zero Drift of Output Voltage: ≤±0.1V
Signal-noise ratio (SNR): ≥80dB
Output Connector: 4mm banana connector
Protection: Over current protection
Signal Ground: Connected to the case and power line
Supply Voltage: 110V~250VAC，50Hz/60Hz
Operating Temperature: 0°C ~ 45°C
Storage Temperature: -20°C ~ 50°C
Humidity: ≤80% RH，no condensation
Size: 365*163*365mm (w * h * d)
