Applicable fiber:SingleMode
Optical connector:ST/SC/FC
Wavelength (nm): 1310,1490,1550±30nm
Dynamic Range:30 dB
Distance range: 2,5, 5, 10, 20, 40, 80, 120, 160, 240 km
Pulse width: 10 to 20000 Ns
Level unit: dBm, mW, µW, nW Relative: Db
Accuracy: ±0,5 m, ±0.5 Db
Resolution:0,01
Memory and logging function: 10 to 16000 data,
Digital distance fault indication
Automatic measurement with threshold level
LSA measurement
Power: From USB port from laptop of PC
Requirements laptop or PC: Vista, Windows 7/9x/NT/2000 and XP versions
Return Loss
Housing:Metal
Size: L: 158,8 mm; W: 76,2 mm; H: 31,8 mm,323 323 gram (unit only)
Operation Temperature, Humidity: 0°C to +40°C, 95% w
Qualified: CE, RoHS and WEEE
