Control System: Embedded fanless PC (Intel Celeron® N3350, 1.1GHz, dual core, 4GB RAM, 32GB SSD hard drive), Ubuntu Linux Operating System
Communications: Standard: WIFI, Ethernet (LAN) Optional modem: Cellular IP 3G HSPA or 4G LTE
Software:
Aeroqual Connect instrument operating system.
Aeroqual Cloud instrument monitoring, management and technical support via secure cloud servers, accessed via web browser (IE,
Firefox, Chrome, Safari).
• Cloud standard features; configuration, calibration, diagnostics, remote technical support.
• Cloud optional features; text (SMS) and email alerts, 3rd party sensor measurements, full data visualisation with charts, wind and
pollution roses, data reporting with auto data export via FTP and API, full instrument event journal capture.
Data logging: 32 GB Hard Drive (> 5 years data storage)
Outputs: 2 x Relay (optional), 4 x 4-20mA (optional)
Averaging period: 1 min, 5 min, 10 min, 15 min, 20 min, 30 min, 1 hr, 2 hr, 4 hr, 8 hr, 12 hr, 24 hr
Power requirements: 100-260 VAC (standard): 36.6aW / 31.3b W Regulated 12 VDC (if required): 40.3a W / 34.3bW
Enclosure: Lockable IP65 GRP cabinet with integrated aluminum solar shield armor
PM Sampling System
Inlet: Omni-directional 36 cm (14.1 inches) heated inlet; Optional sharp cut cyclones for PM10, PM2.5 or PM1 size selection
Pump: 12 V brushless DC diaphragm
Optics: 670 nm laser, near-forward scattering nephelometer with sheath air protection
Dimensions: 483 H x 330 W x 187 D mm (19 H x 13 W x 7.4 D inches)Includessolar shield armor & mounting brackets
Weight: < 13 kg (28.6 lbs)
Environmental operating range: -10 °C to +45 °C (14 °F to 113 °F)
Mounting: Pole, tripod and wall mounting brackets included47mm
Sample Filter (Optional): 47mm filter for particle loading analysis
