Nominal Load :20 t
Nominal Sensitivity: 2 mV/V
Sensitivity Tolerance: ≤ ± 0.1%
Temperature Effect (10 °C):
a) on zero: ≤ ± 0.028 %
b) on sensitivity: ≤ ± 0.020 %
Linearity: ≤ ± 0.05 %
Hysteresis: ≤ ± 0.05 %
Repeatability: ≤ ± 0.02 %
Input Resistance: 700 ± 5 Ω
Output Resistance: 700 ± 2 Ω
Insulation Resistance: >5 GΩ
Zero Balance: ≤ ± 1 %
Recommended Supply Voltage: 10 V
Nominal Supply Voltage: 1-15 V
Maximum Supply Voltage: 18 V
Mechanical Limit Values Referred To Nominal Load::
a) service load: 120%
b) max permissible load: 150%
c) breaking load: >300 %
d) max transverse load: 50%
e) max permissible dynamic load: 50%
Displacement At Nominal Load: ~ 0.2 mm
Reference Temperature: +23 °C
Temperature Nominal Range: -10 / +40 °C
Service Temperature: -20 / +70 °C
Storage Temperature: -20 / +80 °C
Weight: ~ 7.5 kg
Protection Class (En 60529): IP67
Execution Material: Stainless Steel
Connector Output: M12 5 Poles Male connector
Fixing Screws:
a) diameter: M20
b) resistance class: 12.9
c) tightening torque: 400 Nm
