Accuracy Class: ≤± 0.020 %
Linearity Error: ≤± 0.015 %
Input Signal: from 0.5 to 4.5 mV/V
Connectable Load Cells: N° 1 350Ω or 700Ω (4 wires)
Load Cell Excitation: 3V ± 3%
Internal Resolution: 24 bit (2.000.000 div)
Standard Resolution (2Mv/V): ± 50.000 div
Readings Per Sec. (0 Filter) In Direct Reading: 10 Hz
Reference Temperature: +23 °C
Working Temperature Range: 0 / +50 °C
Storage Temperature Range: -10 / +60 °C
Relative Humidity: < 90 % non condensed
Temperature Effect (1°C):On Zero: ≤± 0.015%
Temperature Effect (1°C):On Full Scale: ≤± 0.005%
Custom Lcd Display
Character Height 13 Mm
Programmable Lighting From 1 To 60 Seconds
Blue Led Lighting
Bar Analog Indication
Prog. Measurement Resolution: 1, 2, 5, 10
Programmable Digital Filter: from 0 to 5
Zero And Auto Zero Function: Enabled up to 100% F.S.
Peak Function: COMPRESSION and TENSION
Auto Power Off Function: from 1 to 30 minutes
Menu Lock Function: Programming protection
Calibration With Full Scale: Compression and tension
Calibration With Mv/V Programming: from 0.5 to 4.5 mV/V
Calibration With Points Linearization: 5 points in comp. + 5 points in tension
Units Of Measurements : Kg – t – N – daN – kN - lb
Digital Output: USB 2.0
Continuous Transmission Of Measurements: 10 measure per second
Transmission On Request: on REQUEST or CONTINUOS
Maximum Distance: 5m
Internal Battery Power Supply: Li-Ion 1800mA/h 3.6V RECHARGEABLE
Rechargeable Battery: from USB port (5Vdc)
Autonomy: ~ 80 hours
Recharging Time: ~8 hours by PC or USB power supply
Degree Of Protection (En 60529): IP40
Metallic Enclosure: ALUMINUM
Weight: ~ 0.4kg
