Ingress Protection: IP30
Operating Temperature: 0~50 °C (32~122 °F)
Relative Humidity: 10~95% RH (non-condensing)
Shock Protection: 50 G, half sine
Vibration Protection: 2 Grms, random
Certification: CE, FCC, UL, CCC, BSMI
CPU: Intel® ATOM E3815 1.46GHz Single-Core
Graphics Engine: Intel® HD Graphics
Memory: 1 x Onboard Memory with 4 GB DDR3L 1066 MHz
OS Support: Microsoft® Windows 10 2019 LTSC, WES7, Linux
Power Input: 10~30 VDC
Storage: 32 GB eMMC, 1 x mSATA (shared with mPCIe)
Displays: 1 x HDMI
Expansion: 1 x Full-size mPCIe Slot
LAN Ports: 2 x 10/100/1000 Mbps
Power Connector: 1 x 2-Pin Terminal Block
Serial Ports: N/A
USB Ports: 3 x USB 2.0, 1 x USB 3.0
Dimension (W x H x D): 100 x 70 x 60 mm
Enclosure: Aluminum housing
Weight (Net): 0.6 kg (1.2 lb)
