BIOS: AMI EFI X64
Timer: Programmable timer with 255 intervals (1 ~ 255 seconds)
Processor: Intel ® Atom® x6413E quad-core CPU, 1.5 GHz
Memory: 8 GB DDR4 2666 MHz onboard
Graphics engine: Intel ® UHD Graphics
Ethernet: 2 x Intel i210IT
indicator LEDs: Power, Run (programmable), LAN (Active, Status)
Storage: 64 GB eMMC onboard (up to 256 GB upon request); optional mSATA shared with mPCIe slot
Expansion slot: 1 x Full-size mPCIe slot (SATA/PCIe/USB2.0 signal)
Hardware Security: TPM2.0 (Library Reversion 1.38)
LAN: 2 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000BASE-T Fast Ethernet
USB: 2 x USB 3.2 (Gen 1)
Display Output: 1 x HDMI (1920 x 1080 @60Hz)
Power connector: 1 x 2-pin terminal block
Operating Temp.: -20 ~ 60 °C/-4 ~ 140 °F @ 5 ~ 85% RH with 0.7 m/s
Storage Temp.: -40 ~ 85 °C/-40 ~ 185 °F
Humidity: 10 ~ 95% RH @ 40 °C/104 °F, non-condensing
Shock: Operating, IEC 60068-2-27, 50G, half sine, 11 ms
Vibration: Operating, IEC 60068-2-64, 2 Grms, random, 5 ~ 500 Hz, 1hr/axis (mSATA)
Ingress Protection: IP30
Dimension (W x D x H): 33.5 x 70 x 100 mm/1.3 x 2.8 x 3.9 in
Form Factor: Pocket size
Enclosure: Aluminum
Mount Options: DIN-rail
Weight: 0.5 kg/1.1 lb
Power Requirement: 10 ~ 30V DC
Power Consumption: 15.8W (typical), 35W (max.)
Operating System: Windows 10 LTSC, Windows 11, Ubuntu 20.04, Ubuntu Core 20
Software Compatibility: Canonical Ubuntu Core 20 certification WISE-DeviceOn WISE IoT Edge
