Dimension (L x W x H): PC-240: 195 x 230 x 150 mm (7.68\\
Weight: 3.3 Kg
Disk Drive Bay: 2.5\\
Fan: 1 (12cm/82CFM)
Air Filters: yes
USB: 8
LAN: 2
Video Output: HDMI, VGA
Audio: Mic-in, Line-out
Serial Port: 2 x RS-232/422/485 support auto flow control
Remove SW: for control power on/off signal
DC Outlet: 12V@2A max; 5V@2A max
I/O Module: Hỗ trợ Advantech iDoor
Add-On Card Module: 1 PCIe x16 / 1 PCIe x4 / 2 PCI
Control: Power switch
Indicator LEDs: Power / Disk / CPU Temp. Alarm / System Temp. Alarm / CPU Fan Alarm / Watch Dog
Operating Temp.: 0 ~ 45 °C
Non-Operating Temp.: -40 ~ 85 °C
Humidity: 95% @ 40 °C (non-condensing)
Vibartion (5-500 Hz): SSD: 2 Grms @ 5 ~ 500 Hz, random, 1 hr/axis | HDD: 0.5Grms @ 5 ~ 500 Hz, random, 1 hr/axis
Shock: 10G, IEC-68-2-27, half-sine wave, 11 ms duration
