CPU: Intel® Celeron® J1900 processor, 2.0 GHz
Memory: Dual channel DDR3L-1333 (low power 1.35V), 4 GB memory built in, supports up to 8 GB
Graphics: Intel® HD Graphics, Up to 224 MB SDRAM of shared system memory, VGA: 2560 x 1600 @ 60Hz
Ethernet: LAN 1/2: 10/100/1000 Mbps Intel® I211GigaLAN controller, supports Wake-on-LAN
Audio: Line-Out, Mic-in
Serial Ports: 4 x RS-232/422/485, 1 x COM1, and 1 x COM2 with 5V/12V power, supports auto-flow control
USB: 6 (1 x USB 3.0, 4 x USB 2.0, 1 x internal USB 2.0 type A)
PS/2 Port: 1 supports PS/2 mouse and keyboard
Parallel Port: D-sub 25-pin connector
Digital I/O: 8-bit digital IO (DB9 connector)
Watchdog Timer: 255-level timer intervals, setup via software
Storage:: 2 x 2.5” SATA HDD/SSD bays (9.5 mm height), 1 x mSATA or SATAII
PCI/PCIe: 3 x PCI, 1 x full-size mini PCIe. Supports 15W max. power and 99 x 186 mm max. dimensions (W x L) for PC expansion board
OS Support: Microsoft Windows 7/8.1/Embedded and Linux Fedora 19
Power Type: ATX / AT
Input Voltage: 9V @ 6.6A ~ 30V @ 2A
Power Adapter: AC-to-DC, 65 W DC 19 V / 3.4 A
Power Consumption: 9.9 W ~ 12.9 W
Construction: Aluminum housing
Mount Options: Desk/wall mounting
Dimensions (W x H x D): 137 x 189 x 221 mm
Weight: 4.2 kg (9.24 lbs)
Operating Temperature: With 2 x industrial SSDs without PC expansion boards: -20 ~ 60 °C with 0.7m/sec air flow. With 1 x 2.5\\
Storage Temperature: - 40 ~ 85 °C (-40 ~185 °F)
Relative Humidity: 95% @ 40 °C (non-condensing)
Vibration: With 2.5\\
EMC: CE/FCC, CCC, BSMI
Safety Certifications: CCC, BSMI
