- Temperature Range: -32 ~ 900°C (-25.6 ~ 1652°F)
- Spectral Range: 8 ~ 14 μm
- Resolution: 0.1°C on interface,< 0.025% of temp. range at the analog output
- Emissivity ε: 10.0 ~ 100.0% (adjustable via interface)
- Transmittance t: 10.0 ~ 100.0% (adjustable via interface)
- Measurement Uncertainty:
1% of measured value + 1°C + 1 (ε=1, Tamb=15 ~ 40°C)
1.4% of measured value + 1°C + 1 (ε=1, Tamb=0 ~ 15 or 40 ~ 70°C)
- Repeatability: < 0.3% of measured value (ε=1)
- Noise (NETD, σ = 1): < 0.2°C (ε=1, t90=min, Tamb=23°C)
- Sighting: Eyepiece: Diopter type
Electrical:
- Power Supply: 15 ~ 30 VDC
- Output: Analog output 4 ~ 20 mA, digital output for connecting a USB adapter
- Load: Max 375 Ω at 15 V up to max 1125 Ω at 30 V
Communication and Interface:
- Exposure Time t90: 95 ms (adjustable to 0.5 up to 120 s)
- Connection Cable: 2 m
Environmental
- Protection system: IP 65 (DIN 40050)
- Ambient Temperature: 0 ~ 70°C (32 ~ 158°F) at housing
- Storage Temperature: -20 ~70°C (-4 ~ 158°F)
- Weight: 150 g
- Housing: Stainless steel
- CE Label: According to EU directives about electromagnetical immunity
